18-20-21-24-28-30-32-36m
● "FPT N67" TIER 4B/STAGE IV (UREA) 6 CYLINDERS ENGINE. RATED POWER: 151 KW (205 HP) AT 2200 RPM.MAX POWER: 165 KW (224 HP) AT 1800 RPM
● FOUR WHEEL DRIVE MECHANICAL TRANSMISSION WITH DANA DIFFERENTIAL AND 2 MECHANICAL SPEED
● DANFOSS HYDROSTATIC TRANSMISSION FOR ADVANCEMENT BY CONTINUOSLY VARIABLE SPEED (WORK: 0-25 Km / h; TRANSFER: 0-40 Km / h) WITH PROPORTIONAL DISPLACEMENT MOTORS AND PUMP WITH ELECTRONIC CONTROL
● “CRUISE CONTROL" , CONSTANT WORKING SPEED FUNCTION BY ELECTRONIC CONTROL ON WORK OR TRANSFER MODE
● “AUTOMOTIVE-MODE” JUST ONE CONTROL DEVICE TO OPTIMIZE THE ENGINE RPM RELATED TO THE ADVANCMENT SPEED
● "ECO MODE" IN TRANSFER MODE THE ENGINE IS WORKING AT THE LOWEST RPM POSSIBLE (1500 rpm)
● HYDRAULIC STEERING SYSTEM WITH 4 STEERING WHEELS IN VARIOUS OPTIONS WITH ELECTROMECHANICAL GEAR CONTROL. ELECTRONICALLY CONTROLLED WHEEL REALIGNMENT
● ELECTRONIC SELF ADJUSTING CONTROL ON FRONT AND REAR SUSPENSION
● OIL-BATH DISC BRAKES ON FRONT AND REAR DIFFERENTIAL
● NEGATIVE SAFETY PARKING BRAKE
● 100% DIFFERENTIAL REAR WHEEL LOCK
● GROUND CLEARANCE 700mm
● POLYETHYLENE TANK
● PANIRAMIC ROPS CAB HOMOLOGATED FOR 2 PERSONS, ELECTRONIC CLIMATE CONTROL (EN 15695-1 CAT. 4) WITH ONE FILTER
● ELECTRONIC 6 VENT CLIMATE CONTROL
● PNEUMATIC SEAT AND FOLDING FRONT PASSENGER SEAT
● MULTIFUNCTIONAL ARMREST WITH 7" LED DISPLAY FOR ENGINE MANAGEMENT AND DIAGNOSTICS
● STEREO WITH MEDIA PLAYER (MP3, USB, SD), REMOTE CONTROL AND BLUETOOTH HANDSFREE
● REFRIGERATED COMPARTMENT
● ELECTRONICALLY ADJUSTABLE REAR VIEW MIRRORS
● SYSTEM WASHING KIT WITH ELECTRICAL CONTROLS ON THE CAB
● HYDRAULIC FOLDING BOOM
● TRIJET JETS WITH 02 POLYMER AIR INDUCTION AND XR04-06VK CERAMIC NOZZLES
● PARALLELOGRAM HYDRAULIC BOOM HEIGHT ADJUSTMENT, STROKE 1600mm
● HYDRAULIC SELF-LEVELLING DEVICE WITH CONNECTING RODS
● HYDROPNEUMATIC GAS ACCUMULATOR BOOM SUSPENSION FITTED ON THE BOOM LIFT.
● ELECTROHYDRAULIC BOOM CONTROL WITH 24 FUNCTIONS JOYSTICK
● "B" Touch 800 (8" TOUCH SCREEN) SPRAYCOMPUTER
● Ø19mm 5 WAYS ELECTRICAL PROPORTIONAL CONTROL UNIT (BOOMS 18/21 M)
● Ø19mm 7 WAYS ELECTRICAL PROPORTIONAL CONTROL UNIT (BOOMS 24/36 M)
● 35lt MIXER
● 250lt (3000-3500), 350lt (4000) CLEAR WATER TANK WITH SYSTEM CLEANING DEVICE
● 250lt/min DIAPHRAGM PUMP FOR SPRAYING AND AGITATION
● INDICATOR KIT FOR DIAPHRAGM DAMAGE AND OIL LEAKAGE
● QUICK COUPLING FOR TANK FILLING HOSE
● WHEELS: 300/95 R46 (1725 x 309) WITH BOLTED FLANGE
● 3 FIXED POSITIONS TRACK (REVERSING THE WHEELS OR CHANGING FLANGES POSITION):
1800 - 2000 - 2250mm
● FIXED TRACK, DIFFERENT FROM STANDARD, WITH WHEELS 380mm WIDE AT LEAST.
● MUDGUARDS
